--- title: How do I update DLS-140 firmware? description: How to perform routine and legacy Firmware upgrades to the DLS-140 --- [Skip to content](https://go.skytrac.ca/knowledge/-#main-content) ![SKYTRAC Logo-Color-3](https://go.skytrac.ca/hs-fs/hubfs/SKYTRAC%20Logo-Color-3.png?width=250&height=45&name=SKYTRAC%20Logo-Color-3.png) Open main navigation Close main navigation - [skytrac.ca](https://www.skytrac.ca/) [skytrac.ca](https://www.skytrac.ca/) How can we help you? - There are no suggestions because the search field is empty. 1. [Help Center](https://go.skytrac.ca/knowledge) 2. [Transceivers and Hardware](https://go.skytrac.ca/knowledge/transceivers-and-hardware) 3. [DLS-140](https://go.skytrac.ca/knowledge/transceivers-and-hardware#dls-140) # How do I update DLS-140 firmware? ### Before you start - **Get the firmware from us.** The right version depends on how your DLS-140 is installed (for example, standalone or paired with an ISAT-200A), so we supply firmware per aircraft. Don't reuse a file from another aircraft or an old email. Contact [support@skytrac.ca](mailto:support@skytrac.ca) with the aircraft registration, the DLS-140 serial number and the current firmware version. - **Check the current firmware version.** Connect to the web interface (see *How do I access the DLS-140 web interface?*). - **Prepare the laptop.** - We recommend Windows 11 and Google Chrome. - Unzip the package and save the files to a folder on the laptop. - Disconnect from any VPN. - **Use stable power.** Put the aircraft on ground power for the whole update. Turning the DLS-140 off part-way through can leave it unrecoverable, and it would then have to be returned for repair. - **Save the current settings (03.xx only).** On the **Configuration** tab, press the download button at the top right to save a copy of the current configuration. 1. DLS-140 firmware 2. ISAT-200A firmware 3. ISAT-200A parameter file (.ini)**If the DLS-140 is paired with an ISAT-200A**, update in this order: You can update the unit in the hangar. To confirm satellite signal afterwards, the aircraft needs to be outside with a clear view of the sky. ### Update A: the unit is already on 03.xx firmware 1. Connect to the DLS-140 Wi-Fi (network name **DLS-140-** followed by the serial number, password **skytrac!**) or by Ethernet. 2. Go to **192.168.111.1** and log in with **skytrac / skytrac**. 3. Open the **Configuration** tab and find the **Firmware Update** section. 4. Click **Choose File** and select the **.raucb** file from the package. 5. Click **Upload**. If an **Update** button appears after the upload, press it. 6. Watch the progress bar for errors. The update takes several minutes, and the unit restarts on its own when it's done. 7. Reconnect, log in, and check that **Firmware Version** under System Info shows the new version. The 03.xx interface only accepts .raucb files. If it accepts the file, it is the right type of file. ### Update B: converting a unit from the earlier SkyLink firmware to 03.xx This is done in two stages. **Stage 1: load the conversion file** 1. Connect to the unit's Wi-Fi (network name **Skylink-…**, password on the unit label) or by Ethernet. 2. Go to **192.168.111.1**, click **Login** (top right) and log in with **admin / admin**. 3. Open **Advanced** from the left-hand menu. 4. Under **System Update**, click **Choose File** (or **Browse…**) and select **update.tpz** from the conversion folder in the package. 5. Click **Upload Firmware**. 6. **Wait up to 20 minutes and don't turn the unit off.** The unit restarts during this stage. **Stage 2: load the 03.xx firmware** 1. The Wi-Fi network is now called **DLS-140**, and its password is **skytrac!**. Connect to it. 2. Go to **192.168.111.1**. You should see a plain page with a **Choose File** button and an **Upload & Install** button. If the old SkyLink page appears instead, force a reload with **Ctrl + Shift + R** (**Cmd + Shift + R** on a Mac). 3. Click **Choose File**, select the **.raucb** file (for example, *skytrac-bundle-dls-140-03.02.08.raucb*), then click **Upload & Install**. 4. The page won't show progress. Wait several minutes for a new network named **DLS-140-** followed by the serial number to appear (for example, DLS-140-0000-158A). 5. Connect with the password **skytrac!**, go to **192.168.111.1** and log in with **skytrac / skytrac**. The interface now has Dashboard, Network, Configuration and Diagnostics tabs. **Check the result** - The Dashboard shows the new firmware version. - **ICCID** numbers appear for both Cellular and Satellite. If either is blank, contact Customer Support. - On the **Configuration** tab, **Routing Preference** shows **Cellular Primary** and **Firewall** is set to **unrestricted**, unless SKYTRAC has given you different settings for your aircraft. This conversion is one-way. Once converted, the unit can't be returned to the earlier firmware in the field. ### After any update - Carry out the functional tests in the ESB, and record the ESB number, its revision and the firmware version in the aircraft records as the ESB instructs. - If the unit is paired with an ISAT-200A, load the ISAT-200A firmware and parameter file we supplied. - Take the aircraft outside and check that cellular and satellite signal bars appear. **If the update fails** - **Upload fails or stops part-way:** - The file should be unzipped and saved on the laptop's own drive, not in OneDrive or a network folder. - Use the right file type for the interface: .raucb on 03.xx, .tpz on SkyLink. - Use Chrome, and disconnect from any VPN. - Try once more, then stop and contact support. - **Can't open the web interface:** see the web-access FAQ. - **The unit doesn't come back** (no Wi-Fi network, or the LED stays red): wait at least 20 minutes, then contact support **before** power-cycling it. - This advice is my recommendation, based on ESB0259's warning that powering off during the update requires an RMA. No source gives a recovery procedure, so engineering should confirm whether a power cycle after 20+ minutes is safe. ### Need help? Contact SKYTRAC Customer Support at **[support@skytrac.ca](mailto:support@skytrac.ca)** or **+1 250 765 2393**. Please include: - the aircraft registration - the DLS-140 serial number and mod status - the current firmware version - [Flight following and Account Management](https://go.skytrac.ca/knowledge/flight-following-and-account-management#main-content) - [SkyWeb](https://go.skytrac.ca/knowledge/flight-following-and-account-management#skyweb) - [TrooTrax](https://go.skytrac.ca/knowledge/flight-following-and-account-management#trootrax) - [WebSentinel](https://go.skytrac.ca/knowledge/flight-following-and-account-management#websentinel) - [Asset Manager](https://go.skytrac.ca/knowledge/flight-following-and-account-management#asset-manager) - [Transceivers and Hardware](https://go.skytrac.ca/knowledge/transceivers-and-hardware#main-content) - [ISAT-200A](https://go.skytrac.ca/knowledge/transceivers-and-hardware#isat-200a) - [SkyNode S100 and S200](https://go.skytrac.ca/knowledge/transceivers-and-hardware#skynode-s100-and-s200) - [DZMx](https://go.skytrac.ca/knowledge/transceivers-and-hardware#dzmx) - [RockAIR](https://go.skytrac.ca/knowledge/transceivers-and-hardware#rockair) - [Sky Connect Trackers](https://go.skytrac.ca/knowledge/transceivers-and-hardware#sky-connect-trackers) - [DLS-140](https://go.skytrac.ca/knowledge/transceivers-and-hardware#dls-140) - [Activation and deactivation](https://go.skytrac.ca/knowledge/activation-and-deactivation) - [Installation Manuals](https://go.skytrac.ca/knowledge/installation-manuals) - [Contacting SKYTRAC](https://go.skytrac.ca/knowledge/contacting-skytrac#main-content) - [Technical Support](https://go.skytrac.ca/knowledge/contacting-skytrac#technical-support) - [Sales](https://go.skytrac.ca/knowledge/contacting-skytrac#sales) - [Billing](https://go.skytrac.ca/knowledge/contacting-skytrac#billing) - [Aftermarket](https://go.skytrac.ca/knowledge/contacting-skytrac#aftermarket) - [Cockpit dialers and displays](https://go.skytrac.ca/knowledge/cockpit-dialers-and-displays#main-content) - [CDP-300 and DVI-300](https://go.skytrac.ca/knowledge/cockpit-dialers-and-displays#cdp-300-and-dvi-300) - [MMU-II](https://go.skytrac.ca/knowledge/cockpit-dialers-and-displays#mmu-ii) - [SKYTRAC Mobile](https://go.skytrac.ca/knowledge/skytrac-mobile) - [General Troubleshooting & FAQ](https://go.skytrac.ca/knowledge/general-troubleshooting-faq) [![SKYTRAC Logo-White](https://go.skytrac.ca/hs-fs/hubfs/SKYTRAC%20Logo-White.png?width=170&height=31&name=SKYTRAC%20Logo-White.png "SKYTRAC Logo-White")](https://www.skytrac.ca) | **Technical support** [support@skytrac.ca](mailto:support@skytrac.ca) +1 (250) 765-2393 Answered 24/7 | **Aftermarket and RMAs** [aftermarket@skytrac.ca](mailto:aftermarket@skytrac.ca) Repairs and returns | | --- | --- | Copyright © 2026, SKYTRAC Systems
